SteadyWin WK6025 Motor
Regular price
$29.00
Sale price
$29.00
Regular price
Unit price
SteadyWin WK6025 Motor
Product description
SteadyWin WK6025 Motor Specifications
PRODUCT PARAMETERS
| Parameter | WK6025-3 |
|---|---|
| Nominal voltage | 36V |
| Nominal current | 7.4A |
| Nominal torque | 1.77N.M |
| Nominal speed | 504rpm |
| Max speed | 720rpm |
| Stall torque | 2.68N.m |
| Stall current | 10.67A |
| Winding turns of motor | 30T |
| Interphase resistance | 3.35Ω |
| Interphase inductance | 3.73mH |
| Speed constant | 20rpm/v |
| Torque constant | 0.23N.M/A |
| Rotor inertia | 1069gcm^2 |
| Number of pole pairs | 14Pairs |
| Working temperature | -20~80℃ |
| Max demagnetize temperature | 120℃ |
| Inner diameter of the stator | 35.5mm |
| Motor size | Ø68*30.5mm |
| Motor weight | 345g |
