Unitree A1 Motor
Regular price
$545.00
Sale price
$545.00
Regular price
Unit price
- We automatically select the most cost-effective carrier from China for each destination country
- Shipping rates are dynamically calculated based on real-time quotes
- Final rates may vary due to promotional offers or carrier adjustments
Unitree A1 Motor
Product description
Unitree A1 Motor Specifications
| PRODUCT PARAMETERS | |
| Model | A1 |
| Weight | About 605g |
| Maximum Current | 40A |
| Maximum Rotational Speed | 21.0rad/s(@24VDC) |
| Reduction Ratio | 1:9 |
| Maximum Torque | 33.5NM |
| Torque Constant | 0.8732Nm/A |
| Communication Mode | RS-485 |
| Communication Control Frequency | 1000Hz |
| Motor Encoder Resolution | 15bit |
| Working Voltage | 12V~30VDC 24VDC recommend |
| Motor Perceptual Feedback | Torque, Angle, Angular Velocity, Angular Acceleration, Temperature |
| Motor Control instruction | Torque, Angle, Angular Velocity, Stiffness, Damping |
