SteadyWin WK8110 Motor
Regular price
$23.00
Sale price
$23.00
Regular price
Unit price
SteadyWin WK8110 Motor
Product description
SteadyWin WK8110 Motor Specifications
PRODUCT PARAMETERS
| Parameter | WK8110-3 |
|---|---|
| Nominal voltage | 24V |
| Nominal current | 2.49A |
| Nominal torque | 0.93N.M |
| Nominal speed | 349rpm |
| Max speed | 566rpm |
| Stall torque | 2.4N.m |
| Stall current | 6.51A |
| Winding turns of motor | 30T |
| Interphase resistance | 2.29Ω |
| Interphase inductance | 2.32mH |
| Speed constant | 24rpm/v |
| Torque constant | 0.39N.M/A |
| Rotor inertia | 1716gcm^2 |
| Number of pole pairs | 21Pairs |
| Working temperature | -20~80℃ |
| Max demagnetize tempersture | 120℃ |
| Inner diameter of the stator | 58.5mm |
| Motor size | Ø90*14mm |
| Motor weight | 206g |
