SteadyWin GIM8108-8 Planetary Reducer Motor
Product description
SteadyWin GIM8108-8 Planetary Reducer Motor Specifications
PRODUCT PARAMETERS
| Parameter | Value | Value | Value |
|---|---|---|---|
| Model | GIM8108-8 | GIM8108-8 | GIM8108-8 |
| Driver Model | GDS68 | GDZ468 | GDZ468H |
| Nominal Voltage | 48V (12-56V range) | 24V (12-40V range) | 48V (12-48V range) |
| Power | 336W | 180W | 229W |
| Nominal Torque | 7.5 N·m | 6.6 N·m | 6.71 N·m |
| Stall Torque | 22 N·m | 18.31 N·m | 23.09 N·m |
| Nominal Speed after Reduction | 110 RPM | 196 RPM | 256 RPM |
| Max Speed after Reduction | 320 RPM | 308 RPM | 290 RPM |
| Nominal Current | 7A | 7.5A | 4.78A |
| Stall Current | 22A | 24.2A | 18.86A |
| Phase Resistance | 0.67 Ω | 0.21 Ω | 0.72 Ω |
| Phase Inductance | 0.37 mH | 0.37 mH | 0.37 mH |
| Speed Constant | 6.04 rpm/v | 6.04 rpm/v | 6.04 rpm/v |
| Torque Constant | 1 N·m/A | 1.32 N·m/A | 1.19 N·m/A |
| Number of Pole Pairs | 21Pairs | 21Pairs | 21Pairs |
| Gear Ratio | 8:1 | 8:1 | 8:1 |
| Gear Type | Planetary | Planetary | Planetary |
| Reducer Gear Material | STEEL | STEEL | STEEL |
| Reducer Gear Backlash | 15 arcmin | 15 arcmin | 15 arcmin |
| Motor Weight (without Driver) | 378g | 378g | 378g |
| Motor Weight (with Driver) | 396g | 396g | 396g |
| Size (without Driver) | Ø92*44mm | Ø92*44mm | Ø92*44mm |
| Size (with Driver) | Ø92*55mm | Ø92*55mm | Ø92*55mm |
| Max Axial Load | 225N | 225N | 225N |
| Max Radial Load | 900N | 900N | 900N |
| Noise | <60 dB | <60 dB | <60 dB |
| Communication | CAN | CAN & RS485 | CAN & RS485 |
| Second Encoder | YES | YES | YES |
| Protection Grade | IP54 | IP54 | IP54 |
| Operating Temperature | -20℃ to +80℃ | -20℃ to +80℃ | -20℃ to +80℃ |
| Encoder Resolution | 16 Bit | 14 Bit | 14 Bit |
| Separate Encoder Support | NO | NO | NO |
| Custom Brake Support | YES | YES | YES |
