PaXini PX3Q Joint Torque Sensor
Product description
PaXini PX3Q Joint Torque Sensor Specifications
PRODUCT PARAMETERS
| Parameter | Value |
|---|---|
| Resolution | 0.1 %FS* |
| Sampling Rate | 1000 Hz* |
| Diameter | 50 mm / 60 mm / 70 mm (Customizable) |
| Height | 9 mm / 9 mm / 11 mm (Customizable) |
| Weight | 50 g* |
| Material | Aluminum Alloy |
| Limited Overload | 300% |
| Repeatability | 0.1 %FS* |
| Overall Accuracy | 0.5 %FS* |
| Operating Temperature | -10 ~ 80 °C |
| Water and Dust Resistance | IP64 (IP67/IP68 Customizable) |
| Operating Voltage | 9 ~ 24 VDC |
| Communication Protocols | RS485 / CANFD / EtherCAT / USB, and others |
