PaXini PX-6AX GEN3 Multidimensional Tactile Sensor
Regular price
$70.00
Sale price
$70.00
Regular price
Unit price
PaXini PX-6AX GEN3 Multidimensional Tactile Sensor
Product description
PaXini PX-6AX GEN3 Specifications
PRODUCT PARAMETERS
| Parameter | Value |
|---|---|
| Number of Force Signals in Array | Maximum 121 |
| Range of Force | 0 - 25 N (normal), ± 10 N (tangential) |
| Operating Temperature | 0 - 50°C |
| Overload Temperature | -20 - 120°C |
| Flame Retardant Grade | V-0 (the highest UL94 flame classification) * |
| Service Life | Supports over 10 million cycles * |
| Sampling Rate | 1 MHz |
| Maximum Output Frequency | 1000 Hz * |
| Minimum Recognition Force | 0.01 N * |
| Spatial Resolution | 0.1 mm * |
| Safe Overload | 200% |
| Shock Overload | 300% |
| Repeatability | <0.5%FS |
| Water and Dust Resistance | IP65 |
| Stray Magnetic Field Immunity | Chip-level anti-magnetic capability |
| Operating Voltage | 3 to 5 volts |
| Surface Coverage | Comprehensive coverage on the frontal and lateral curved surfaces |
| Dynamic Temperature Compensation | Preserved |
| Torque Perception | Supports torque measurement at any point |
