LINKERBOT Linker Hand O20 Robotic Dexterous Hand
Product description
LINKERBOT Linker Hand O20 Specifications
| PRODUCT PARAMETERS | |
| Degrees of Freedom | 16 |
| Number of Joints | 16 Active DoF |
| Transmission Method | Direct Drive |
| Drive Method | Self-Developed Joint Module |
| Control Interface | CAN FD |
| Weight | 888g |
| Max Load | 36kg |
| Operating Voltage | DC24V±10% |
| Quiescent Current | 0.45A |
| Average Current for No-Load Movement | 1.1A |
| Maximum Current | 3.1A |
| Repeat Positioning Accuracy | -- |
| Maximum Thumb Tip Force | 7N |
| Maximum Four-Finger Tip Force | 9N |
| Thumb Lateral Rotation Range | 1.14rad (65.24°) |
| Four-Finger Bending Angle | 1.611rad (92.33°) |
| Thumb Side-Swing Speed | 1.55rad/s (89.07°/s) |
| Four-Finger Bending Speed | 2.18rad/s (124.69°/s) |
| Thumb Bending Speed | 2.01rad/s (115.24°/s) |
