HESAI AT1440/360 LiDAR
Regular price
$9,915.00
Sale price
$9,915.00
Regular price
Unit price
HESAI AT1440/360 LiDAR
Product description
HESAI AT360 LiDAR Specifications
| PRODUCT PARAMETERS | |
| Model | AT360 |
| Scanning method | 1-D rotating mirror (hybrid solid-state) |
| Number of channels | 360 (300 enabled) |
| Ranging capability | 250 m (at 10% reflectivity) |
| Ranging accuracy | ±5 cm (typical) |
| Ranging precision | 3 cm (typical, 1σ) |
| FOV (H × V) | 120° × 18° (-9° to +9°) |
| ROI (H × V) | 35° × 12° (-6° to +6°) |
| Resolution (H × V) | ROI: 0.06° × 0.05° Non-ROI: 0.12° × 0.10° |
| Frame rate | 10 Hz |
| Return mode | Dual Return: First and Strongest |
| Wavelength | 905nm |
| Laser class | Class 1 Eye Safe |
| Ingress protection | IP6K7 & IP6K9K |
| Dimensions | 158 × 119 × 52 (WDH, mm) |
| Rated voltage range | DC 9 to 16 V |
| Power consumption | 16 W |
| Operating temperature | -40°C to 85°C |
| Storage temperature | -40°C to 105°C |
| Weight | 1080 g |
| Data transmission | Automotive Ethernet, 1000BASE-T1, slave mode |
| Measurements | Distance, azimuth angle, and reflectivity |
| Valid point rate | 5700000 points/sec |
| Point cloud data rate | 233/672 Mbps (avg/peak) |
| Clock source | PTP (802.1AS AUTOSAR) |
| PTP clock accuracy | ≤1 µs |
| PTP clock drift | ≤5 µs/s |
