FEETECH FT9025M Servo Motor
Product description
The FT-9025-C001 is a high-precision 6V 8.5kg.cm digital servo featuring a coreless motor and durable metal gears, enclosed in an aluminum housing for enhanced durability. Engineered with ball bearings and a 25T/5.9mm horn gear spline, it operates efficiently within a 4.8-6V voltage range. At 6V, this digital comparator servo delivers a peak stall torque of 8.5kg.cm and an ultra-fast no-load speed of 0.133sec/60°. Driven by pulse width modification (500–2500 µsec), it provides a 180° running degree and an ultra-precise dead band width of ≤4 µsec. With no mechanical limit angle and a lightweight design of 35.2±1g, it offers reliable performance across a -20°C to 60°C temperature range.
FEETECH FT-9025-C001 Specifications
| PRODUCT PARAMETERS | |
| Model | FT-9025-C001 |
| Product Name | 6V 8.5kg.cm Digital 180 Degree Aluminum Case Metal Gear Coreless Servo |
| Storage Temperature Range | -30℃~80℃ |
| Operating Temperature Range | -20℃~60℃ |
| Size | A：36mm B：15mm C：29.2mm |
| Weight | 35.2± 1g |
| Gear type | Metal Gear |
| Limit angle | NO limit |
| Bearing | Ball bearings |
| Horn gear spline | 25T/5.9mm |
| Case | Alumi num |
| Connector wire | 25CM |
| Motor | Coreless Motor |
| Operating Voltage Range | 4.8-6V |
| Idle current (atstopped) | 6MA@6V |
| No load speed | 0.133sec/60°@6V |
| Runnig current(at no load) : | 200mA@6V |
| Peak stall torque | 8.5kg.cm@6V |
| Rated torque | 2.8kg.cm@6V |
| Stall current | 1.4A@6V |
| Command signal | Pulse width modification |
| Amplifier type | Digital comparator |
| Pulse width range | 500~2500 μ sec |
| Stop position | 1500 μ sec |
| Running degree | 180°(at 500→2500μsec) |
| Dead band width | ≤4 μ sec |
| Rotating direction | Counterclockwi se (at 1500→2000 μ sec) |
